| 標配處理器CPU(規格/數量) | Build in Intel Socket 1151 Core? i7/Core? i5/Core? i3/for XeonR E3-1200 v5 and 6th genereation CoreTM, Pentium and Celeron Processors | | | | |
|---|
| 記憶體 (Std/Max) | 4 x DIMM, Max. 64GB, DDR4 2133 MHz ECC, Non-ECC, Un-buffered Memory | | | | |
|---|
| PCI插槽 | 1 x PCIe 3.0/2.0 x1 (x1 mode) *1、1 x PCIe 3.0/2.0 x16 (x16 mode) 、1 x PCIe 3.0 x4 (x8 mode) *1 | | | | |
|---|
| 網路介面 | Intel I210, 2 x Gigabit LAN Controller(s) | | | | |
|---|
| 傳輸介面 | 1 x DVI-D、1 x DisplayPort、1 x HDMI、2 x LAN (RJ45) port(s)、2 x USB 3.1 Gen 1 、2 x USB 2.0、1 x Optical S/PDIF out、1 x USB BIOS Flashback Button(s)、1 x 8-channel Audio I/O | | | | |
|---|
| OS Support | Windows 10 86x64、Windows 8.1 86x64、Windows 7 SP1 、Windows Server 2008 R2、Windows Server 2012 R2 | | | | |
|---|
| Management Solution | WfM 2.0, DMI 3.0, WOL by PME, WOR by PME, PXE | | | | |
|---|
| I/O 輸出入埠 | 1 x AAFP connector、2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s) 、1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)、1 x M.2 Socket 3、1 x TPM header、8 x SATA 6Gb/s connector(s)、1 x CPU fan with PWM control、1 x S/PDIF out header(s)、1 x 8-pin EATX 12 V Power connector、1 x 24-pin EATX Power connector(s)、1 x Front panel connector(s) (1 x 19 -pin)、1 x AUX panel header(s)、4 x Front fan、1 x Rear fan、1 x COM port header、1 x Chassis intrusion header | | | | |
|---|
| 晶片組 | Intel C236 Chipset |
|---|
